Build to Perform

Microprocessor pH Meter

Features:

Attachment for Serial Dot Matrix / Thermal Printer Microprocessor Based pH Meter Model 1015 is a solid state instrument designed to provide the precise pH and mV measurements. The instrument uses the latest Microprocessor technology and advanced engineering techniques so as to give enhanced accuracy and reproducibility. The system has user friendly prompts which guide you through out the measurement process.



The system has 8 soft touch membrane type keys for ease of operation. It has facility for doing upto 5 point calibration. It has the storage facility for 999 samples, which are retained in the memory even when the system is switched OFF. Provision has also been provided for attachment of centronics dot matrix printer so that any of the stored results can be printed.

The instrument is extremely useful for agriculture and soil analysis laboratories, swimming pools, water quality control in boiler feed water, water works department, fertilizer plants, petroleum refineries, breweries, water purification plants etc.

Specifications:

pH-Range-2.000 to 20.000 pH
pH-ResolutionSelectable 0.1, 0.01, 0.001 pH
pH-Accuracy+/- 0.002 pH +/- 1 digit
pH-Read Out128 x 64 dots Graphical LCD Display
pH-CalibrationAuto & Manual with 5-points Calibration
pH-Auto Buffer Recognition1.680, 4.000, 7.000, 9.200 & 12.450 pH or User Selectable
pH-Relative Stability+/- 0.002 pH/Hour
Temperature Compensation-5 to 110oC Auto/Manual
mV -Range0 +/- 1999.9 mV
mV -Resolution0.1 mV
mV -Accuracy+/- 0.1 mV, + 1 digit
Temperature-Range-5.0 to 110oC
Temperature-Resolution0.1oC
Temperature-Accuracy+/- 0.1oC
Temperature-SensorSemi Conductor Type
Temperature-Power Supply12V DC using 230+10% AC Adaptor
Temperature-Printer InterfaceExternal Serial RS 232 Dot Matrix Printer Interface
Temperature-AccessoriesCombination pH Electrode, Temperature Probe, Buffer Tablets 4 pH & 7pH, Electrode Stand, Mains Lead, Instruction Manual, Dust Cover

Note :

Specifications are subject to change due to continuous improvements.
